Situated in the Thi Qar province, approximately 5km northwest of Al-Refaei city and 85km north of Nasiriya, the Garraf oil field has an onshore location. Discovered in 1984, this oil field contains oil reserves within Cretaceous reservoirs. Spanning 17.5km in length and 5.5km in width, it is estimated to harbor 1.3 billion barrels of oil. Upon reaching full production, the field’s production capacity is projected to escalate to 230,000 barrels of oil per day (bopd). Transportation of the oil field’s products is facilitated through a 13km pipeline to the Gharraf-Badra tie-in area (GBTA). Subsequently, it is conveyed via a 28-inch, 92km pipeline to the Nassiriyah storage depot.

The project aims to replace the temporary Let Down Station, installed in 2015, with permanent pressure reduction facilities at the expansion area of GS. This upgrade is intended to transport gas to the local market and supply the existing Sirte Oil Company (SOC) coastal gas pipeline with an increased capacity of 19.5 MSm3/d of sales gas at a higher pressure of 51 Bar.

An innovative ultra-deep-water offshore project, the Kaombo project in Block 32 aims to extract oil from six fields linked by 300km of pipelines to FPSO vessels. Operating at depths up to 1,950 meters, it utilizes advanced technology for its 658 million barrel reserves, with a production capacity of 230,000 b/d, making it Angola’s largest subsea well system. Through cutting-edge technology and engineering, it pushes the boundaries of traditional oil exploration, demonstrating Angola’s commitment to advancing its energy sector.
